FLT Frame Hardtail Unit
FLT Frame Hardtail Unit
Regular price
$705.56
Sale price
$705.56
Unit price
/
per
Shipping calculated at checkout.
Out of stock
Mfg/Brand: V-Twin
SKU:51-1336
Harley Model / Year Fitment: FLT 2009-UP,
Frame hardtail unit is bolt on type for alignment to facilitate welding in place.
2 inch longer than stock tubes feature an 1-1/4 inch outer diameter to match existing lower frame tube. Alignment relies on the swingarm pin with bushings and upper rear frame section with 4 bolt attachment points. *NOTE: Must order a 1 inch or 25mm axle separately. Axle plates are machined for a 1 inch axle. *NOTE: For required OEM alignment components refer to a FLT factory parts book. *NOTE: Lower fender bracket installed. Top plate aligns with 3 holes in seat plate and the lower portion mounts to the transmission swingarm pin location. This hole features a 5/8 inch inner diameter. Lower mounts use dowel pins to drive into existing holes in lower frame rails. OEM Parts listed are for alignment purposes and are on original chassis. OEM rear frame section is not required for alignment. *NOTE: Primarily for installation on 2009-2016 models but can be adapted to most Touring frames.
MFG Part #:
Technote: Required to use with OEM#47540-11 Swingarm Axle available separately. Required to use with OEM#33285-07A 6-Speed Transmission Assembly available separately. Required to use with OEM#48487-02 Outer Swingarm Spacer available separately. (2 needed) Require
Dimensions:
Replaces OEM:
Made in: TAIWAN
Available Replacement Components / Related Part #s : 51-1880 , 51-0510 , 51-0466
NOTE: Part installation instructions are not provided unless a link is shown below:
