HARLEY Knucklehead UL Frame Kit Fits 1938-1940 UL, 1938-1940 EL,
HARLEY Knucklehead UL Frame Kit Fits 1938-1940 UL, 1938-1940 EL,
Regular price
$4,918.78
Sale price
$4,918.78
Regular price
$5,123.73
Unit price
/
per
Shipping calculated at checkout.
Out of stock
Mfg/Brand: V-Twin
SKU:55-0555
Replica frame is an authentic reproduction of the factory style featuring 13 brazed joints. The 28� rake neck angle will accept inline spring forks. Features original DIF forging marks on the left side of the neck. Frame will accommodate Knucklehead or Big Twin Flathead engine and 3 or 4-speed transmission. Horizontal frame cross bar features 7/8 inch O.D. tubing. Frame includes seat post mechanical brake cross shaft rear axle assembly transmission plate and a motor alignment plate for safer shipping. Cross shaft bushings seat post bushing correct tool box mount and grease fittings are pre-installed.Updated Knucklehead frame features forgings with the markings inchHot Forged inch in place. Forged parts include: Neck front and rear motor mounts yoke side car loops and rear axle plates. For original look on rear axle plates the rear brake slot on the left side must be cut out at the front. We have left this inchclosed inch for the builder to remove as desired. FITS HARLEY: 1938-1940 UL, 1938-1940 EL,
MFG Part #:
Technote: Required to use with #49-0099 Coil Mount Kit Parkerized. In some instances it may be necessary to ream or file holes slightly in order to assemble parts onto the frame. *NOTE: Seat post and cross shaft bushings may require further reaming for proper fit. *NOTE: There are no serial numbers stamped on the replica frame. V-Twin supplys a Bill of Sale only referencing the the part number. *NOTE: UPS may consider this part as packages inchoversizeinch forshipment as compared to the actual weight which will result in higher shipping costs.
Dimensions:
Replaces OEM:
Made in: TAIWAN
NOTE: Part installation instructions are not provided unless a link is shown below:
