HARLEY XR 750 19 inch x 2.50 inch Rear Flat Track Wheel Fits W 1937-1952, K 1952-1956, XL 1957-1

HARLEY XR 750 19 inch x 2.50 inch Rear Flat Track Wheel Fits W 1937-1952, K 1952-1956, XL 1957-1

$545.92
$545.92 $590.18
Shipping calculated at checkout.

Hurry up! Only 4 items in stock.

Expected delivery date:
12 Oct Orders ship in 3-4 business days
Mfg/Brand: V-Twin

52-0071

Harley Model / Year Fitment: W 1937-1952, K 1952-1956, XL 1957-1978, XR 1970-1984,
19 inch WR/KR/XR rear wheel features a natural finish hub with 9/16 inch ball bearings and internals installed. Laced with 6-8 gauge stainless steel spokes and nipples to a chrome finish 19 inch x 2.50 inch 40 hole steel rim.
Sold laced and trued! Includes 1 lock nut 2 required. Wheel hub has a 9/16 inch inner diameter. Ball bearings are installed. Acccepts an 11/16 inch axle shaft Shinko SR267 front and SR268 rear tires. *NOTE: All spokes on wheel need to be inspected and re-torqued after 500 miles of original installation. *NOTE: Wheels accept metal stem inner tubes. The hub is splined on both sides to accept the sprocket and brake disc. **NOTE: Wheel accepts splined quick change sprocket or sprocket disc adapter flange (carrier). *NOTE: 19 inch x 2.50 inch width rim will fit dirt track medium compound tube type inchTourist Trophy inch tires. *Note: UPS may consider this part as packaged inchoversize inch for shipment as compared to the actual weight which will result in higher shipping costs.
MFG Part #: 61026
Technote: Recommended to use with V-Twin #45-0115 XR Rear Sprocket Carrier. Suggested to use with #46-0077 Shinko SR267 130/80 x 19inch Front Flat Track Tire Medium. Suggested to use with #46-0079 Shinko SR268 140/80 x 19inch Rear Flat Track Tire Medium.
Dimensions:
Replaces OEM:
Made in: TAIWAN
Available Replacement Components / Related Part #s : 52-0752 , 46-0277 , 45-0149 , 45-0115 , 45-0107 , 44-0482 , 19-0144
